130101. RG 59 Standard (Vedio Cable)

RG 59 Standard (Vedio Cable)

Detailed description

Cable Structure
Inner conductor ø mm	1x0,81 Solid BC or CCS
Insulation ø mm	3,5 Foam PE
Shield	95% BC Braid
Outer jacket	5.0 FR-PVC
Power Cord
Steel Messenger ø mm
Electrical characteristics
Impedance (Ohm)	75±3
Min. Velocity Propagation	84%
Norminal Atten at 20°(dB/100m)
5 MHz	2.82
55 MHz	6.73
211 MHz	12.47
250 MHz	13.45
300 MHz	14.60
400 MHz	16.73
500 MHz	18.70
750 MHz	22.87
1000 MHz	26.64
5-1000 MHz	>21dB
1000-2000 MHz	>18dB
2000-3000 MHz	>15dB
